Product name：15kV/200A Single-Pass Elbow Connector
Product model：NRDTZT-217
产品参数 Product parameters
| Rated voltage | 8.7/15kV |
| Rated current | 200A |
产品介绍 Product introduction
15kV / 200A single elbow cable joint is a combination of single sleeve and elbow cable joint.
Provide more wiring scheme and operation space for box transformer.
Cooperating with the casing base, it provides the same function as the two-way casing joint. The front end can be connected with elbow cable joint and install cable. The rear end is connected with lightning arrester or 200A protective cap and elbow plug.
One way elbow type connectors are plug-in terminals.
Cable section range: 35 ~ 150mm ².
